Flatbed Container Trailers

40ft flatbed container trailers 3 Axle 40ft flatbed container trailer s with 12R22.5 tires is the most popular trailer for transporting 20ft or 40ft containers.We have exported many flatbed trailers to all the world for working very well. Welcome you inquiry very soon. 40ft flatbed container...

Inquiry

  • Product Details

40ft flatbed container trailers
 3 Axle 40ft flatbed container trailers with 12R22.5 tires is the most popular trailer for transporting 20ft or 40ft containers.We have exported many flatbed trailers to all the world for working very well. Welcome you inquiry very soon.

40ft flatbed container trailers:


Tri-axle flatbed container trailers


Advantages-flatbed container trailers
 1. 40ft Flatbed Container trailer can use it to carry One 40ft and two 20ft cargo containers at one time and also deliver products like pipe , steel , lumber and any other item you want.
 2. High strength frame:Torsion - resistan of Main Longitudinal Beams("I" high strengh steel) and Transverse Beam (channel beam)
 3. All the parts of Flatbed Semi Trailer are purchased from famous brand product like Jost Lading Gear, WABOCO emergency brake, BPW Axle.That made Flatbed Semi Trailer more reliable, exhibiting great strength and a long time time of use
 4. 40ft Flatbed Container Trailer includes a 3 mm thickness flat platform that is made of checkered plates. Ridges flatbed create more friction, thus making it slip-resistant.
 5. Surface treatment: Pretreatment to coating , apply sandblast to the whole structure, zinc-rich primer puls acrylic polyurethane top coating.
 6. Delivery time within 15 working days.

Specification-flatbed container trailers

Flatbed container trailers

Dimension

12.5m×2.5m×1.55m (Outside)

Payload

50T

Tare weight

About 7.5T

Twistlock

12 units

Frame Floor

The Thickness is 3mm pattern

Edge beam

16# Channel

Through beam

10#Channel

Along beam

6#Channelx6

Axle

3 axles, 13T FD brand 16ton brake pads

Landing Gear

28T lifting capacity with two speed

King Pin

2.00 or 3.5 inch bolt-in king pin

Suspension

Mechanical suspension reforced type

Leaf Spring

90mm(W)*16mm(T)*10 Layer

Tire

12R22.5*12pcs ,Triangle brand

Note: All the details not mentioned above should comply with Chinese regulations.If any component or structure changed,the price shall be modified accordingly.
